100Mbps UHF Software Defined Radio IP Mesh Radio For UGVs And Robotics

  • 1
  • 2

Brand Name : IWAVE

Model Number : FD-780X

Certification : CE, MIC

Place of Origin : CHINA

MOQ : 2

Price : Negotiable

Payment Terms : T/T,L/C,D/P

Supply Ability : 5000000/month

Delivery Time : 5-10days

Packaging Details : Standard Carton Box

Name : Software Defined Radios IP Mesh Radios

Size : 52*46.5*2.9mm

Latency : 5-15ms

Anti-jam : FHSS

Data Rate : 100Mbps uplink and downlink

Hops : 32hops

Frequency : Dual-band 600Mhz and 1.4Ghz

Encryption : AES128

Contact Now

100Mbps UHF Software Defined Radios IP Mesh Radios For UGVs And Robotics

Introduction

The FD-780X is the most advanced, scalable, and efficient Mobile Ad Hoc Networking (MANET) system available, now offered in a SWaP-optimized Embedded Module form factor. This module allows seamless integration into your products, connecting UAVs, UGVs, and sensors on a unified network. With its built-in HD video encoder and onboard computer, the Embedded Module reduces the need for additional, redundant equipment on your platform.

Advantages of Software Defined Radios IP Mesh Radios (FD-780X)

  • Fluid self-healing mesh optimized for mobile applications

  • Excellent range and Non-Line-of-Sight (NLOS) capability

  • Each node can act as a data source as well as a repeater

  • Transparent IP network allows connection of any general IP device

  • Auto adaptive modulation maintains connectivity in mobile applications

  • MIMO and Standard IP Mesh capability

  • Up to 32 nodes on a single frequency network

  • IP Mesh Radios for meshed drones

  • IP Mesh radios for UGVs

  • Up to 100Mbps throughput

  • Enhanced GPS performance

  • On-board Ethernet magnetics

  • 200MW total output power

  • Low latency Mesh radios – under 15ms for video and data

  • Optional AES128 encryption

  • Low power consumption, typically 5Watt

  • Range NLOS – >1km and single hop >10km air to ground

 100Mbps UHF Software Defined Radio IP Mesh Radio For UGVs And Robotics

Specification of Software Defined Radios IP Mesh Radios

Function items

Description

Details

PCB

single-sided interface board

Tolerance range:

46.58±0.15mm

52.00±0.15mm

2.90±0.10mm

RF

RF Band 1

1420-1530MHz

RF Band 2

566-678MHz

Power Level

1.4G 23dBm±2

600MHz 23dBm±2

Sensitivity

(1Mbps)

1.4G(14700 channel)

20MHz -102dBm

10MHz -100dBm

5MHz -96dBm

600M(6200 channel)

20MHz -102dBm

10MHz -100dBm

5MHz -96dBm

Interface

UART

3

HSIC

USB 2.0 High Speed

USB

USB 2.0 High Speed

I2C

2 个

GPIO

23 个

JTAG

0 个

RF

2T2R

Power

VSYS

3.7V~4.35V,suggest 4.0V (input)

D1V8A

1.8V output

A2V85A

2.85V output

VCC_D3V3

3.3V output

5V_FEM

RF PA chip power supply(Input)

Network

Network Mode

Centerless Ad Hoc Network

Capacity

Max 32nodes

Hops

Support multi-hop routing topology, up to 31 hop

Communication

Supports unicast, multicast, and broadcast transmission modes. Any nodes can use these three modes for communication

Data Rate

All nodes communicate and share the working bandwidth, and the max rate is 100Mbps

Time Synchronization

Independent of external clock, self-synchronous

Power Control

All nodes adaptively adjust the transmission power

Subnet Fusion

Support splitting one network into multiple networks

Movement Speed

Maximum support 300km/h

Retransmission

HARQ Retransmission

Anti-jam

Supports dynamic frequency hopping within and across frequency bands

100Mbps UHF Software Defined Radio IP Mesh Radio For UGVs And Robotics
